If you make the wrong choice of resin for your project, it could have bad results. This is because certain resins need a longer curing time and others require a low viscosity for easy pouring. If you have a thin pouring resin and you apply it too thick on your substrate, it will automatically accelerate the curing process and could result in yellowing or cracking of the epoxy. Yet again certain epoxies rely on complicated mixing ratios as well as catalysts, where others have a simple 1:1 mixing ratio. Also, you have different types of resins such as Polyester Resin, Casting Resin, Epoxy Coating Resin and so on, the list appears to be endless. So, to make better choices, we need to know the difference between Epoxy and Resin. Below we will be learning a little more about epoxy vs resin.

Various types of Resin

In theory, it appears that there is an unlimited variety of epoxies on the market. This can pose a tremendous problem when it comes to choosing the correct resin for your project. Do not worry, for, in reality, there are only a few types for you to choose from. This is because the majority of these unlimited epoxies have been modified slightly to suit particular project needs.

So, in reality, there are only four ordinary or regular types of epoxy resins in stores to choose from.  Resin vs Epoxy: below is a list of these main resin categories:

• Polyester Resin: This is not an actual epoxy but is rather an unsaturated synthetic resin
• Epoxy Resin: This type is supplied in 1 or 2 component forms
• Polyurethane Resin: This is also not an actual epoxy but is rather a synthetic resin or plastic
• Epoxy Acrylates: These are a type of blend that is formed by linking polyester and pure epoxy resin

The difference between Epoxy and Resin

Trying to differentiate between resin and epoxy is not the way to be looking at things. If you consider the term Epoxy Resin or Casting Resin, they both have their own type of blend. So, when you are likening the two, you are actually relating the differences between Epoxy Coating Resin, Casting Resin, or Polyester Resin and not the difference between Epoxy and Resin.

When considering Polyester Resin, this type is used mainly in the marine industry and seeing this is a DIY Epoxy Site, we will be concentrating rather on the difference between Epoxy Coating Resin and Casting Resin.



Casting Resin vs Epoxy Coating Resin

The most noticeable difference between these two compounds is their intended use. The Epoxy Coating Resin is intended for coating surface applications, while the Casting Resin is used mainly for jewelry, molds or figurines. However, we need to realize that both of these two compounds could be used interchangeably, but we will discuss this matter later on in the article.



Pouring Depth Maximum

Most Epoxy Coating Resins have a recommended maximum pouring depth of 1/8 to 1/4 of an inch for each application. If you then exceed these recommended maximum pouring depths per application, it may cause an accelerated curing reaction.

However, with some of the Casting Resins, you can pour thicker layers per application, as much as several inches thick. With this feature, Casting Resins are more suitable for use in molds, river tables, figurines and in projects where various items are embedded deep in the resin.

The Thickness or Viscosity of the Material

When comparing the two compounds, Epoxy Coating Resins are usually thicker than Casting Resins. The reason being that Casting Resins have a slower curing rate, and as such creates less heat which will allow you to pour thicker layers. This characteristic of Casting Resin will be a problem when it is used for coating applications, as the resin is thinner and tends to run off the sides of your project. To avoid this happening, you will have to build a frame around your project to hold the resin in place.



Curing Times

Curing times for Casting Resins are a lot slower than for Epoxy Coating Resins. Casting Resins can cure in 24 to 48 hours, while Epoxy Coating Resins cure in 12 to 24 hours. Epoxy Coating Resins will cure to the touch within 20 minutes, but Casting Resins will take up to 18 hours to begin to gel.

Casting Resins can make thicker pours, which releases heat a lot slower than Epoxy Coating Resins. So, if you pour an Epoxy Coating Resin too thick it could destroy your project, as the heat released can crack your epoxy.



Processing Time

The working time is not to be mistaken for curing time. This process, working time, is also referred to as pot or gel time and is the time taken for your epoxy to start to gel or set. Once you have reached this point, you will not be able to work without difficulty or easily pop any bubbles that arise. This means that Casting Resins give you a longer working time, as it cures a lot slower.

Epoxy Coating Resins give you around 20 minutes working time, which is considerably less time needed to prepare everything and still pour. Be careful, because you can reduce the working time even more, when you pour it in on very hot days, or if you let it stand in your mixing container too long before you decide to pour it.



Hardness

In most cases, your Epoxy Coating Resins appear to be harder than the Casting Resins. This is because the Casting Resins allow a variation in mixing ratios, which affects its hardness. This is especially evident, for example, when Casting Resins are used as artificial water in a vase. This means that if the Casting Resin is not flexible, the vase will eventually crack when the glass contracts and expands.

So, when using Casting Resins for this type of application you need to make it more flexible, which you can accomplish by altering the amount of hardener you use. Just be careful, as each Casting Resin is different, so you need to follow the manufactures instructions very carefully and only use a resin that is suited for your application. Many have found that Epoxy Coating Resins have a better scratch resistance than that of Casting Resins.

Mixing Ratios

Broadly speaking, most Casting Resins have mixing ratios of 3:1, 2:1 and also 1:1. However, Epoxy Coating Resins usually have mixing ratios of 1:1. This appeals to many users, as they find it a lot easier to work with. If you vary your mixing ratios such as 3:1 or 2:1, you will have to have mixing containers where you gradually add the resin to make sure the ratios are measured out accurately. Whatever mixing ratio you use, it needs to be measured out precisely or else your epoxy will not cure correctly.

UV Resistance

Epoxy Coating Resins, as well as Casting Resins, are both able to contain UV inhibitors. However, when Casting Resin is used for your outside projects and it is exposed to UV rays, yellowing is more evident because it is thicker. Also, if they do not contain paint, stain or color the yellowing can be more obvious.

As far as resistance to yellowing goes, all epoxy resins are different. Epoxy Coating Resins, for example, seem to hide yellowing better when they contain dark colored stains and paint or when used in the wood grain. Take note that most of the Epoxy Coating Resins and the Casting Resins are not recommended for outdoor projects or where they are exposed to continual UV rays.



Heat Resistance or Tolerance

Most of the Epoxy Coating Resins and the Casting Resins used by the average DIY artist are not high heat resistant epoxies. The epoxies that fall in the high heat resistant epoxies category tend to be expensive. The average Epoxy Coating Resins and the Casting Resins all start to soften in the region of 110 to 150° F. This aspect needs to be carefully considered by those DIY enthusiasts that are interested in projects like coasters, countertops, or any other project where hot items like pots, coffee cups, pans etc. will be used.

Possibility of bubbles

There is a strong possibility of bubbles forming when Casting Resin is poured into a mold where certain items are embedded. However, when the Resin is poured in much thinner layers, there is a much slighter possibility of bubbles forming as the bubbles rise to the surface and are easily popped.

However, if you take time and prepare your project properly beforehand, you will considerably reduce the possibility of bubbles forming. All porous materials such as wood, for example, could pose a problem, so you need to give it a thin sealing coat first.

This sealing coat will then flow easily into all the cracks and porous areas sealing them off. This same process of applying a sealing coat should also be followed when you are going to embed any items in your epoxy. If you have an item or a mold that has corners, grooves or hard to get areas, should also be sealed before poring, as they are inclined to trap and hold air bubbles in the epoxy.



Other Types of Epoxy Resins

Polyurethane Resin

If you want to use Polyurethane Casting Resin for your projects, make sure that you first check its characteristics and ensure that it is compatible with your project. This is an excellent resin to use and has several good pros and only a very few cons.
